间距PITCH: 1.25mm
极数POLE: 2-15poles
额定电压RATE VOLTAGE: 125V AC,DC
额定电流RATE CURRENT: 1A (28AWG)
耐压值WITHSTAND VOLTAGE: 250V AC/minute
接触阻抗CONTACT RESISTANCE: 20mΩ(MAX.)
绝缘阻抗INSULATION RESISTANCE: 100MΩ(MIN.)
工作温度范围: -40℃~+85℃
应用P.C.B厚度APPLICABLE P.C.B THICKNESS: 0.8mm
应用P.C.B孔径APPLICABLE P.C.B HOLE DIA.: ø0.5±0.05
应用线规APPLICABLE WIRE RANGE: 28AWG~32AWG
