0.5mm 60PIN FPC连接器 上接

FPC Pitch 0.5mm H=2.0 4-60P Upper Contact SMT

Enable a digital display connection
DisplayPort handles digital transfers at rates up to 10.8Gbps. Support 2560x1600.2048x1536 high resolution.
It support deep color 30/36 bit.
It supports digital audio and video, with bandwidth to spare to accommodate future enhancements up to 21.6G b/s.
It support RSA for digital content protection.
Applications: PC,Projector,DVD Player,Set Top Box,LCD TV/PDP TV

Contact Current Rating: 0.5A Min
Voltage Rating: 40V AC(rms)
Withstanding Voltages:500V AC (for 1 minute)
Insulation Resistance: 100M ohms Min.
Contact Resistance: 30m ohms Max.
Working Temperature: -25ºC ~ +85ºC

Insulator Material: High Temperature Thermoplastic (UL94V-0 rated)
Contact: Copper alloy
Insertion Force: 39.2N Max
Withdraw Force: 9.8N Min
Durability mating cycle: 10,000 cycles min
